    Viewing Instance Information

    Last updated: 2024-07-01 11:33:59
    Download PDF
      1. Log in to the new Anti-DDoS console and click Anti-DDoS Instances on the left sidebar.
      2. On the Anti-DDoS Instances page, you can view the basic information (such as the base protection bandwidth and running status) of your purchased Anti-DDoS Pro instances and the basic information and elastic protection configuration of your purchased Anti-DDoS Advanced instances.

      Directions

      The following shows you how to view the information of the Anti-DDoS Pro instance "bgp-00000jt3".

      1. Log in to the new Anti-DDoS console and click Anti-DDoS Instances on the left sidebar.
      2. On the Anti-DDoS Instances page, select a region or protection package in the top right corner. Find and click the instance ID "bgp-00000jt3" to view the instance details. If there are many instances, you can use the search box in the top right corner for filtering.

      3. On the pop-up page, you can view the following information:


      Parameter
      Description
      Instance name
      The name of the Anti-DDoS Pro instance for easier instance identification and management. You can set a custom instance name containing 1-20 characters of any type as needed.
      Region
      The region selected when the Anti-DDoS Pro instance is purchased.
      Current status
      The current status of the Anti-DDoS Pro instance, such as Running, Cleansing, and Blocked.
      Creating: The instance is being created.
      Running: The instance is providing protection.
      Attacked: Under attacks.
      Blocked: The instance is blocked.
      Unblocking: The instance is being unblocked.
      Reclaiming: The instance has expired and is being repossessed.
      Expiration time
      It is calculated based on the purchase period selected at the time of purchase and the specific time of payment, accurate to the second. Within seven days before the expiration of an Anti-DDoS resource, Tencent Cloud will push expiration reminders to the account creator and all collaborators via Message Center, SMS, email, or WeChat (subject to your configuration in the Message Center).

      The following shows you how to view the information of an Anti-DDoS Advanced instance.

      1. Log in to the new Anti-DDoS console and click Anti-DDoS Instances on the left sidebar.
      2. ‌On the Anti-DDoS Instances page, click the ID of the Anti-DDoS Advanced instance that you want to view the details. If there are many instances, you can use the search box in the top right corner for filtering.

      3. On the pop-up page, you can view the following information:

      Parameter
      Description
      Instance name
      The name of the Anti-DDoS Advanced instance for easier instance identification and management. You can set a custom instance name containing 1-20 characters of any type as needed.
      Destination IP
      The protective IP of the Anti-DDoS Advanced instance. It may change from time to time.
      To avoid DNS resolution failure, you are recommended to change the DNS resolution address to the assigned CNAME.
      Region
      The region selected when the Anti-DDoS Advanced instance is purchased.
      Current status
      The current status of the Anti-DDoS Advanced instance, such as Running, Cleansing, and Blocked.
      CNAME
      The CNAME of the Anti-DDoS Advanced instance. The CNAME will be resolved to the protective IP that forwards cleansed traffic to the real server.
      To avoid DNS resolution failure, you are recommended to change the DNS resolution address to the assigned CNAME.
      Base protection bandwidth
      The base protection bandwidth you select when you purchase the instance. If elastic protection is not enabled, base protection bandwidth is the maximum bandwidth of the instance.
      Expiration time
      ‌It is calculated based on the purchase period selected at the time of purchase and the specific time of payment, accurate to the second. Within seven days before the expiration of an Anti-DDoS resource, Tencent Cloud will push expiration and renewal reminders to the account creator and all collaborators via Message Center, SMS, or email (subject to your configuration in the Message Center).
      Tag
      The tag name of the Anti-DDoS Advanced instance, which can be edited and deleted.
      Forwarding IP range
      The IPs that forward cleansed traffic back to the real server.
