apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    k8s-app: kafka-exporter # 根据业务需要调整成对应的名称，建议加上 Kafka 实例的信息
  name: kafak-exporter # 根据业务需要调整成对应的名称，建议加上 Kafka 实例的信息
  namespace: kafka-demo
spec:
  replicas: 1
  selector:
    matchLabels:
      k8s-app: kafka-exporter # 根据业务需要调整成对应的名称，建议加上 Kafka 实例的信息
  template:
    metadata:
      labels:
        k8s-app: kafka-exporter # 根据业务需要调整成对应的名称，建议加上 Kafka 实例的信息
    spec:
      containers:
      - args:
        - --kafka.server=x.x.x.x:9092 # 对应 Kafka 实例的地址信息
        image: danielqsj/kafka-exporter:latest
        imagePullPolicy: IfNotPresent
        name: kafka-exporter
        ports:
        - containerPort: 9121
          name: metric-port  # 这个名称在配置抓取任务的时候需要
        securityContext:
          privileged: false
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
      dnsPolicy: ClusterFirst
      imagePullSecrets:
      - name: qcloudregistrykey
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      terminationGracePeriodSeconds: 30


  apiVersion: monitoring.coreos.com/v1
  kind: PodMonitor
  metadata:
    name: kafka-exporter  # 填写一个唯一名称
    namespace: cm-prometheus  # namespace固定，不要修改
  spec:
    podMetricsEndpoints:
    - interval: 30s
      port: metric-port # 填写pod yaml中Prometheus Exporter对应的Port的Name
      path: /metrics # 填写Prometheus Exporter对应的Path的值，不填默认/metrics
      relabelings:
      - action: replace
        sourceLabels:
        - instance
        regex: (.*)
        targetLabel: instance
        replacement: 'ckafka-xxxxxx' # 调整成对应的 Kafka 实例 ID
      - action: replace
        sourceLabels:
        - instance
        regex: (.*)
        targetLabel: ip
        replacement: '1.x.x.x' # 调整成对应的 Kafka 实例 IP
        namespaceSelector:
      matchNames:
      - kafka-demo
        selector:  # 填写要监控pod的Label值，以定位目标pod
      matchLabels:
        k8s-app: kafka-exporter
