      "Description": "",
      "Refresh": "close",
      "Title": "JSONTEST",
      "UUID": "jdq4joy56is4w60q",
      "Version": 1,
      "Templating": [],
      "Links": [],
      "Panels": [],
      "Time": {
                "From": "now-12h",
                "To": "now"
        },
}

"Templating": [ // 模板变量
        {
            "Label": "cvm实例名称", // 模板变量别名
            "Multi": true, // 是否多选
            "Name": "cvm", // 标签
            "Selected": [], // 模板变量的值
            "Type": "monitor", // 模板变量的类型
            "TemplatingType": "basics", // 标签的类型：基础监控、自定义监控
      "TemplatingType": '123', // 变量id
        }
    ]

"Links": [ // Dashboard链接
        {
            "IncludeVars": true, // 链接参数是否带上模板变量
            "KeepTime": true, // 链接参数是否带上时间变量
            "TargetBlank": true, // 是否新开选项卡
            "Title": "xxx", // 链接名称
            "Type": "other", // 链接类型：自定义链接和跳转其他Dashboard的链接
            "Url": "/monitor/dashboard2/dashboards/d/0hh64oj49rru3ctk/dashboard2-0yan-shi-an-li-xia-zuan-lian-jie",  // 链接地址
            "ID": 0 // ID
        }
    ]

"Panels": [ // panel配置
        {
            "Collapsed": false,  // 图表组是否折叠
            "Datasource": null, // 数据源
            "GridPos": { // 图表位置
                "H": 1,
                "W": 6,
                "X": 0,
                "Y": 0
            },
            "ID": 1595472129140, // 图表ID
            "Panels": [], // panel为图表组的字段，里面存放子Panel
            "Title": "默认图表组", // 标题
            "Type": "row" // 图表类型
        },
        {
            "DataLinks": [], // 图表配置的数据链接
            "Description": "", // 图表的备注
            "GridPos": {
                "H": 5,
                "W": 6,
                "X": 0,
                "Y": 1
            },
            "ID": 1595471392817,
            "Links": [], // 图表链接
            "Settings": { // 图表的可视化配置
                "aliasColors": {},
                "bars": false,
                "dashLength": 10,
                "dashes": false,
                "datasource": null,
                "decimals": 2,// 图例精度
                "fieldConfig": {
                    "defaults": {
                        "custom": {}
                    },
                    "overrides": []
                },
                "fill": "0.8",// 图表填充透明度
                "fillGradient": 0,
                "gridPos": {
                    "h": 8,
                    "w": 12,
                    "x": 0,
                    "y": 0
                },
                "hiddenSeries": false,
                "id": "1595471392817",// 图表panel的id
                "legend": {// 图例设置
                    "alignAsTable": [// 图例是否以表格形式展示
                        "1"
                    ],
                    "avg": [// 是否显示平均值.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "current": [// 是否显示最新值.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "max": [// 是否显示最大值.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "min": [// 是否显示最小值.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "rightSide": [// 是否放在右边.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "show": [// 是否显示图例.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "total": [// 是否展示累加值.【‘1’】为true；【‘0’】为false
                        "1"
                    ],
                    "values": false
                },
                "lines": [// 是否显示曲线.【‘1’】为true；【‘0’】为false
                    "1"
                ],
                "linesType": true,// 是否展示平滑曲线.【‘1’】为true；【‘0’】为false
                "linewidth": "2",// 曲线宽度
                "markline": {// mark设置
                    "marklineMax": {
                        "max": [// 是否显示峰值.【‘1’】为true；【‘0’】为false
                            "1"
                        ]
                    }
                },
                "nullPointMode": "1",// 数据中空值展示方式：0-连接空数据；1-不填充；2-自动填充为0
                "options": {
                    "dataLinks": []// datalinks数组
                },
                "percentage": false,
                "pointradius": 2,
                "points": false,
                "renderer": "flot",
                "seriesOverrides": [],
                "spaceLength": 10,
                "stack": [// 是否堆积显示。【‘1’】为true；【‘0’】为false
                    "1"
                ],
                "steppedLine": false,
                "targets": [
                    {
                        "refId": "A",
                        "scenarioId": "random_walk"
                    }
                ],
                "thresholds": [],
                "timeFrom": null,
                "timeRegions": [],
                "timeShift": null,
                "title": "新图表",
                "tooltip": {
                    "shared": true,
                    "sort": 0,
                    "value_type": "individual"
                },
                "type": "graph",
                "xaxis": {
                    "buckets": null,
                    "mode": "time",
                    "name": null,
                    "show": true,
                    "values": []
                },
                "yaxes": [
                    {
                        "decimals": 2,// 左侧y轴精度
                        "format": "%",// 左侧y轴lebal单位
                        "label": null,
                        "logBase": 1,
                        "max": 2,// 左侧y轴坐标最大值
                        "min": 0,// 左侧y轴坐标最小值
                        "show": [// 是否展示左侧y轴.【‘1’】为true；【‘0’】为false
                            "1"
                        ]
                    },
                    {
                        "decimals": 2,
                        "format": "",
                        "label": null,
                        "logBase": 1,
                        "max": null,
                        "min": null,
                        "show": [
                            "1"
                        ]
                    }
                ],
                "yaxis": {
                    "align": false,
                    "alignLevel": null
                }
            },
            "Targets": [ // 指标配置
                {
                    "Aggregate": "", // 统计方式
                    "CompareLastWeek": false, // 环比
                    "CompareYesterday": false, // 同比
                    "Conditions": [ // 筛选条件
                        {
                            "Dimension": [
                                "{\\"InstanceId\\":\\"ins-19827u5b\\"}",
                                "{\\"InstanceId\\":\\"ins-xxooxxoo\\"}",
                                "{\\"InstanceId\\":\\"ins-19719mfp\\"}"
                            ],
                            "Region": "ap-guangzhou",
                            "Type": "normal"
                        }
                    ],
                    "ConfigId": "cvm",
                    "Datasource": "DS_QCEMetric", // 产品类型
                    "DimensionKey": [
                        "InstanceId"
                    ],
                    "GroupBy": [ // groupby
                        "InstanceId"
                    ],
                    "MetricNames": [ // 指标名
                        "BaseCpuUsage"
                    ],
                    "Namespace": "QCE/CVM", // 命名空间
                    "Period": 60 // 粒度
                },
            ],
            "Title": "单指标 - 默认配置", // 图表名称
            "Type": "graph" // 图表类型
        },
    ]
