cd electron-vite-vuenpm installnpm run dev
TUIRoom/Electron/packages/renderer/src/TUIRoom
文件夹到已有项目 packages/renderer/src/
目录下。App.vue
组件中引入 TUIRoom 组件。<template><room ref="TUIRoomRef"></room></template><script setup lang="ts">import { ref, onMounted } from 'vue';// 引入 TUIRoom 组件,注意确认引入路径是否正确import Room from './TUIRoom/index.vue';// 获取 TUIRoom 组件元素,用于调用 TUIRoom 组件的方法const TUIRoomRef = ref();onMounted(async () => {// 初始化 TUIRoom 组件// 主持人在创建房间前需要先初始化 TUIRoom 组件// 普通成员在进入房间前需要先初始化 TUIRoom 组件await TUIRoomRef.value.init({// 获取 sdkAppId 请您参考 步骤一sdkAppId: 0,// 用户在您业务中的唯一标示 IduserId: '',// 本地开发调试可在 https://console.tencentcloud.com/trtc/usersigtool 页面快速生成 userSig, 注意 userSig 与 userId 为一一对应关系userSig: '',// 用户在您业务中使用的昵称userName: '',// 用户在您业务中使用的头像链接userAvatar: '',// 用户用于屏幕分享的唯一 Id,要求 shareUserId = `share_${userId}`, 无屏幕分享功能需求可不传入shareUserId: '',// 请您参考本文 步骤一 > 第三步 并使用 sdkAppId 及 shareUserId 签发 shareUserSigshareUserSig: '',})// 默认执行创建房间,实际接入可按需求择机执行 handleCreateRoom 方法await handleCreateRoom();})// 主持人创建房间,该方法只在创建房间时调用async function handleCreateRoom() {// roomId 为用户进入的房间号, 要求 roomId 类型为 number// roomMode 包含'FreeSpeech'(自由发言模式) 和'ApplySpeech'(举手发言模式) 两种模式,默认为'FreeSpeech',注意目前仅支持自由发言模式// roomParam 指定了用户进入房间的默认行为(是否默认开启麦克风,是否默认开启摄像头,默认媒体设备Id)const roomId = 123456;const roomMode = 'FreeSpeech';const roomParam = {isOpenCamera: true,isOpenMicrophone: true,}await TUIRoomRef.value.createRoom(roomId, roomMode, roomParam);}// 普通成员进入房间,该方法在普通成员进入已创建好的房间时调用async function handleEnterRoom() {// roomId 为用户进入的房间号, 要求 roomId 类型为 number// roomParam 指定了用户进入房间的默认行为(是否默认开启麦克风,是否默认开启摄像头,默认媒体设备Id)const roomId = 123456;const roomParam = {isOpenCamera: true,isOpenMicrophone: true,}await TUIRoomRef.value.enterRoom(roomId, roomParam);}</script><style>html, body {width: 100%;height: 100%;margin: 0;}#app {width: 100%;height: 100%;}</style>
npm install sass typescript unplugin-auto-import unplugin-vue-components -S -D
npm install element-plus events mitt pinia trtc-electron-sdk tim-js-sdk tsignaling -S
packages/renderer/src/main.ts
文件。// src/main.ts 文件import { createPinia } from 'pinia';const app = createApp(App);// 注册PiniacreateApp(App).use(createPinia()).mount('#app').$nextTick(window.removeLoading)
packages/renderer/vite.config.ts
中配置 element-plus 组件按需加载。// vite.config.tsimport AutoImport from 'unplugin-auto-import/vite';import Components from 'unplugin-vue-components/vite';import { ElementPlusResolver } from 'unplugin-vue-components/resolvers';const path = require('path');export default defineConfig({// ...plugins: [AutoImport({resolvers: [ElementPlusResolver()],}),Components({resolvers: [ElementPlusResolver({importStyle: 'sass',})],}),],css: {preprocessorOptions: {scss: {additionalData: `@use '${path.resolve(__dirname, 'src/TUIRoom/assets/style/element.scss')}' as *;`,},},},});
// src/main.tsimport 'element-plus/theme-chalk/el-message.css'import 'element-plus/theme-chalk/el-message-box.css'
trtc-electron-sdk
,统一代码风格,否则必须要以 require 的方式引入,需要您在 packages/renderer/vite.config.ts
中配置。// vite.config.tsexport default defineConfig({// ...plugins: [resolve({"trtc-electron-sdk": `const TRTCCloud = require("trtc-electron-sdk");const TRTCParams = TRTCCloud.TRTCParams;const TRTCAppScene = TRTCCloud.TRTCAppScene;const TRTCVideoStreamType = TRTCCloud.TRTCVideoStreamType;const TRTCScreenCaptureSourceType = TRTCCloud.TRTCScreenCaptureSourceType;const TRTCVideoEncParam = TRTCCloud.TRTCVideoEncParam;const Rect = TRTCCloud.Rect;const TRTCAudioQuality = TRTCCloud.TRTCAudioQuality;const TRTCScreenCaptureSourceInfo = TRTCCloud.TRTCScreenCaptureSourceInfo;const TRTCDeviceInfo = TRTCCloud.TRTCDeviceInfo;const TRTCVideoQosPreference = TRTCCloud.TRTCVideoQosPreference;const TRTCQualityInfo = TRTCCloud.TRTCQualityInfo;const TRTCStatistics = TRTCCloud.TRTCStatistics;const TRTCVolumeInfo = TRTCCloud.TRTCVolumeInfo;const TRTCDeviceType = TRTCCloud.TRTCDeviceType;const TRTCDeviceState = TRTCCloud.TRTCDeviceState;const TRTCBeautyStyle = TRTCCloud.TRTCBeautyStyle;const TRTCVideoResolution = TRTCCloud.TRTCVideoResolution;const TRTCVideoResolutionMode = TRTCCloud.TRTCVideoResolutionMode;const TRTCVideoMirrorType = TRTCCloud.TRTCVideoMirrorType;const TRTCVideoRotation = TRTCCloud.TRTCVideoRotation;const TRTCVideoFillMode = TRTCCloud.TRTCVideoFillMode;export {TRTCParams,TRTCAppScene,TRTCVideoStreamType,TRTCScreenCaptureSourceType,TRTCVideoEncParam,Rect,TRTCAudioQuality,TRTCScreenCaptureSourceInfo,TRTCDeviceInfo,TRTCVideoQosPreference,TRTCQualityInfo,TRTCStatistics,TRTCVolumeInfo,TRTCDeviceType,TRTCDeviceState,TRTCBeautyStyle,TRTCVideoResolution,TRTCVideoResolutionMode,TRTCVideoMirrorType,TRTCVideoRotation,TRTCVideoFillMode,};export default TRTCCloud.default;`,}),]// ...});
packages/renderer/src/env.d.ts
中配置。// env.d.tsdeclare module 'tsignaling/tsignaling-js' {import TSignaling from 'tsignaling/tsignaling-js';export default TSignaling;}declare module 'tim-js-sdk' {import TIM from 'tim-js-sdk';export default TIM;}
packages/renderer/vite.config.ts
中配置。// vite.config.tsexport default defineConfig({// ...build: {rollupOptions: {output: {format: 'es'}}},});
npm run dev
release
目录下,可以安装运行。npm run build
TUIRoomRef.value.init(roomData);
参数 | 类型 | 含义 |
roomData | object | |
roomData.sdkAppId | number | 客户的 SDKAppId |
roomData.userId | string | 用户的唯一 ID |
roomData.userSig | string | 用户的 UserSig |
roomData.userName | string | 用户的昵称 |
roomData.userAvatar | string | 用户的头像 |
roomData.shareUserId | string | 非必填,用户进行屏幕分享的 UserId,要求 shareUserId = share_${userId} ,无屏幕分享功能可不传入 |
roomData.shareUserSig | string | 非必填,用户进行屏幕分享的 UserSig |
TUIRoomRef.value.createRoom(roomId, roomMode, roomParam);
参数 | 类型 | 含义 |
roomId | number | 房间 ID |
roomMode | string | 房间模式,'FreeSpeech'(自由发言模式)和 'ApplySpeech'(举手发言模式),默认为 'FreeSpeech',注意目前仅支持自由发言模式 |
roomParam | Object | 非必填 |
roomParam.isOpenCamera | string | 非必填,进房是否打开摄像头,默认为关闭 |
roomParam.isOpenMicrophone | string | 非必填,进房是否打开麦克风,默认为关闭 |
roomParam.defaultCameraId | string | 非必填,默认摄像头设备 ID |
roomParam.defaultMicrophoneId | string | 非必填,默认麦克风设备 ID |
roomParam.defaultSpeakerId | String | 非必填,默认扬声器设备 ID |
TUIRoomRef.value.enterRoom(roomId, roomParam);
参数 | 类型 | 含义 |
roomId | number | 房间 ID |
roomParam | Object | 非必填 |
roomParam.isOpenCamera | string | 非必填,进房是否打开摄像头,默认为关闭 |
roomParam.isOpenMicrophone | string | 非必填,进房是否打开麦克风,默认为关闭 |
roomParam.defaultCameraId | string | 非必填,默认摄像头设备 ID |
roomParam.defaultMicrophoneId | string | 非必填,默认麦克风设备 ID |
roomParam.defaultSpeakerId | String | 非必填,默认扬声器设备 ID |
<template><room ref="TUIRoomRef" @on-room-create="handleRoomCreate"></room></template><script setup lang="ts">// 引入 TUIRoom 组件,注意确认引入路径是否正确import Room from './TUIRoom/index.vue';function handleRoomCreate(info) {if (info.code === 0) {console.log('创建房间成功')}}</script>
<template><room ref="TUIRoomRef" @on-room-enter="handleRoomEnter"></room></template><script setup lang="ts">// 引入 TUIRoom 组件,注意确认引入路径是否正确import Room from './TUIRoom/index.vue';function handleRoomEnter(info) {if (info.code === 0) {console.log('进入房间成功')}}</script>
<template><room ref="TUIRoomRef" @on-room-destory="handleRoomDestory"></room></template><script setup lang="ts">// 引入 TUIRoom 组件,注意确认引入路径是否正确import Room from './TUIRoom/index.vue';function handleRoomDestory(info) {if (info.code === 0) {console.log('主持人销毁成功')}}</script>
<template><room ref="TUIRoomRef" @on-room-exit="handleRoomExit"></room></template><script setup lang="ts">// 引入 TUIRoom 组件,注意确认引入路径是否正确import Room from './TUIRoom/index.vue';function handleRoomExit(info) {if (info.code === 0) {console.log('普通成员退出房间成功')}}</script>
